RADIO STATIONS - TUBE


SPY RADIO RECEIVER AND TRANSMITTER   PARASET  MK VII
Manufactured in England, Whaddon, Year 1940-1942

POWER OUTPUT: 6 W

FREQUENCY: 3,3 – 7,6  MHz

MODULATION: CW

Replica build by Dubravko Rogale





RADIO RECEIVER AND TRANSMITTER USSR RB5
Manufactured in USSR, Year 1940

POWER OUTPUT: 1 W

FREQUENCY: 1,5 – 6  MHz

MODULATION: AM, CW



SOURCE:  Krešo Lerota, 9A3DBC





RADIO RECEIVER AND TRANSMITTER   WIRELESS SET  WS-48
Manufactured in USA, Year 1942

SOURCE:  9A9DR Dubravko, Ljubljana HAM fleamarket





RADIO RECEIVER AND TRANSMITTER BC - 654 - A

Manufactured in USA, Crosley Corporation, Cincinnati, Ohio

US Army Signal Corps

POWER OUTPUT: 20 W

POWER SUPPLY: MOTORGENERATOR

FREQUENCY:  3,8 - 5,8 MHz

MODULATION: AM, CW

SOURCE:  9A3AMQ Milan





REPAINTED RADIO RECEIVER AND TRANSMITTER BC - 654 - A

Manufactured in USA, Crosley Corporation, Cincinnati, Ohio, Year 1942.

 Repainted by former JNA during year 1960.



POWER OUTPUT: 24 W

POWER SUPPLY: MOTORGENERATOR (Dynamotor)

FREQUENCY: 3,8 - 5,8 MHz

MODULATION: AM, CW



SOURCE:   9A5JR / OE3REB   Dr. sc. Ronald Eisenwagner - Ron / ,Krešo Lerota, 9A3DBC

 Jakuševac fleamarket





DYNAMOTOR PE-103-A

FOR RADIO RECEIVER AND TRANSMITTER BC - 654 - A

 Manufactured in USA, Crosley Corporation, Cincinnati, Ohio, Year 1942.

 Repainted by former JNA during year 1960.



TYPE: DYNAMOTOR

POWER SUPPLY:  Power Input: 6 VDC  @  21 A

                                            12 VDC @  11 A

Power Output: 6  or 12 VDC and 500 VDC @ 150 mA.

SOURCE:  9A9DR Dubravko, Jakuševac fleamarket, Mato from Zelina





BX-31A  BOX WITH SPARE PARTS FOR

RADIO RECEIVER AND TRANSMITTER BC - 654 - A

Manufactured in USA, Crosley Corporation, Cincinnati, Ohio, Year 1942.

CONTENTS: SPARE VACUUM TUBES FOR RECEIVER &TRANSMITER

                              BULBS FOR RECEIVER DIAL, TRANSMITER DIAL & ROLLER DIAL

 SPARE VIBRATOR

 SOURCE:  9A9DR Dubravko, Jakuševac fleamarket, Mato from Zelina





T - WIRE ADJUSTABLE ANTENNA

FOR RADIO RECEIVER AND TRANSMITTER BC - 654 - A

 Manufactured in USA, Crosley Corporation, Cincinnati, Ohio, Year 1942.

Repainted by former JNA during year 1960.

TYPE: T-ANTENNA

SOURCE:  9A9DR Dubravko, Jakuševac fleamarket, Mato from Zelina





VIBRATOR POWER SUPPLY PE-237

FOR RADIO RECEIVER AND TRANSMITTER AN/GRC9

Manufactured in USA, Lewyt corp, Year 1942.



TYPE: VIBRATOR POWER SUPPLY

POWER SUPPLY: Power Input: 6 VDC  @  27 A

                                         12 VDC @  13 A,

                                          24 VDC @    7 A,

 Power Output: 2 supplys for voltages: 1.35, 6, 6.5, 105, 525 V and 1.35 & 100 V

SOURCE:  9A9DR Dubravko, Jakuševac fleamarket, Mato from Zelina





RADIO RECEIVER AND TRANSMITTER BC - 659 - A

Manufactured in USA, Galvin mfg Corporation, Chicago, Illinois, Year 1942.

POWER OUTPUT: 1,5 W

POWER SUPPLY: PE-117 Produce: 60, 25.5, -4.5 VDC

FREQUENCY: 27.0-38.9 MHz in 100 kHz steps

MODULATION: FM,   IF 9.3 MHz, 14 tubes

SOURCE:   9A3AMQ Milan





RADIO RECEIVER AND TRANSMITTER  PD-5

SOURCE:  Krešo Lerota, 9A3DBC





PORTABLE RADIO RECEIVER AND TRANSMITTER R-105

Manufactured in Soviet Union - year 1960.

POWER OUTPUT: 1 W

POWER SUPPLY: 2,4 V  -  22Ah accu

FREQUENCY: 36 - 46,1 MHz

MODULATION: FM

SOURCE:   9A6AQK  Branko Runkas





POWER AMPLIFIER    UM-3
Manufactured in Soviet Union

For soviet radio equipment R-105 M,  R-108 M and R-109 M

 SOURCE:  Krešo Lerota, 9A3DBC





RT-77/GRC-9

 "Yugoslav copy of AN/GRC-9"

Manufactured Ei Nis Serbia, first production before 1964



TUBES:  OA2,  ECC82,  6AK6, 6AK6, 6AK6, 6AK6, QQE03/20

                                     TX POWER  20W  with triode  2E22

FREQUENCY: RX/TX  2MHz to 12MHz

MODULATION: AM or CW

SOURCE: 9A3AMQ / 9A5JA, Krešo Lerota, Alemko Hudak, Jure Šlat 9A7KSJ, Marijan Neralić





DY-88/GRC9   Supply transverter for RT-77/GRC-9

Manufactured in USA



MOTOR - DYNAMO SET

POWER SUPPLY:  6, 12, 24 VDC – Accumulator

OUTPUT VOLTAGE:

1,4 V – Receiver tube heating

6,3 V – Transmitter tube heating

105 V – Anode voltage

580 V – Anode voltage for PA tube

SOURCE:  ALENKO HUDAK, MARIJAN NERALIĆ





HAND GENERATOR GN-58-A

FOR RADIO RECEIVER AND TRANSMITTER AN/GRC9

 Manufactured in USA, Crosley Corporation, Cincinnati, Ohio, Year 1942.

 Repainted by former JNA during year 1962.

TYPE:  Manual hand generator



OUTPUTS:

 6,3V / 2,45A

425V / 0,115A

1,4V / 0,45A

105V / 0,032A

SOURCE:  9A9DR Dubravko, Jakuševac fleamarket, Mato from Zelina





RUP-4
"Yugoslav GRC-9"

Manufactured Ei Nis Serbia, first production cca 1964

 TUBES:  TX:OA2,  ECC82,  6AK6, 6AK6, 6AK6, 6AK6, QQE03/20

   RX: Transistor set

TX POWER  20W

FREQUENCY: RX/TX  2MHz to 12MHz

MODULATION: AM or CW

SOURCE: 9A2US   Milan





RUP – 4     (Modernised version)

Manufactured in EI, Niš, Serbia

VACUUM TUBE SET TRANSMITTER RD – 2   TRANSISTOR SET   RECEIVER RP – 2

 POWER SUPPLY: TP – 5

FREQUENCY:  2- 12  MHz

MODULATION: AM/CW

SOURCE:  DUBRAVKO, 9A6NNS





Supply transverter PT-5 for RUP 4

Manufactured in Niš, Serbia

TRANSISTOR SET

POWER SUPPLY: 6, 12 VDC – Accumulator

OUTPUT VOLTAGE: Designed for RUP 4 transmitter:

      Transmitter tube heating

Anode voltage

 Anode voltage for PA tube

SOURCE:  ALENKO HUDAK, MARIJAN NERALIĆ





RADIO RECEIVER AND TRANSMITTER R-112
Manufactured in Soviet Union, year 1950

POWER OUTPUT: 50 W AM & 90 W CW

POWER SUPPLY: 24 V  accu and dynamotor UT-18A and UTK 250

FREQUENCY: 2,8 - 4,99 MHz step 10 kHz - 220 channels

MODULATION: AM, CW

SOURCE:   9A3AWD Ivica, Jakuševac fleamarket





RUSSIAN SPY RADIO RECEIVER AND TRANSMITTER  R-350M

SOURCE:  Krešo Lerota





SPY RADIO RECEIVER, TRANSMITTER & POWER SUPPLY  GRC-109A

SOURCE:  Krešo Lerota





RADIO RELAY UNIT HVT-1

Manufactured in "Iskra" Slovenia, end of 1950-es.

POWER OUTPUT: 20 W impuls

POWER SUPPLY: 220 VAC

FREQUENCY: 1700 - 2300 MHz

MODULATION: PULS FREQUENCY

SOURCE:   9A3CJP Josip Peršin - John via 9A3AWD Ivica





ANTENNA OF RADIO RELAY UNIT HVT-1

Manufactured in "Iskra" Slovenia, end of 1950-es.

POWER OUTPUT: 20 W impuls

FREQUENCY: 1700 - 2300 MHz

DISTANCE: LESS THAN 50 km

MODULATION:  PULS FREQUENCY

SOURCE: 9A6AQK  Branko Runkas





HF TRANCEIVER  PD-6/S

Manufactured in EI, Niš, Serbia

VACUUM TUBE SET

 POWER SUPPLY: OWN POWER SUPPLY

FREQUENCY: 2 – 12 MHz

MODULATION:  AM/SW/LSB

POWER:  150 W

SOURCE: DUBRAVKO 9A6NNS, BRANKO RUNKAS, 9A6AQK





POWER SUPPLY MI-8 FOR  PD-6/S UNIT

Manufactured in EI, Niš, Serbia

TRANSFORMER & VACUUM TUBE SET

 POWER SUPPLY:  220 VAC

 TUBE HEATING VOLTAGES

ANODE VOLTAGES

PA STAGE HIGH VOLTAGES

SOURCE: DUBRAVKO 9A6NNS, BRANKO RUNKAS, 9A6AQK





HF TRANCEIVER  PD-3

Manufactured in EI, Niš, Serbia

VACUUM TUBE SET

 POWER SUPPLY:  OWN POWER SUPPLY

FREQUENCY:  2 – 12 MHz

MODULATION: AM/SW/LSB

POWER:  400 W

SOURCE: ZDENKO, 9A2HI, BRANKO 9A6AQK





RADIO RECEIVER AND TRANSMITTER   WIRELESS SET  WS-12

Manufactured in England, Year 1939.

SOURCE:  Prof. dr. sc. Bojan Jerbić





LOW VOLTAGE POWER SUPPLY MI-12 FOR  PD-3 UNIT

Manufactured in EI, Niš, Serbia

SOURCE: DUBRAVKO 9A6NNS, BRANKO 9A6AQK, Sava dump, Sesvete





HIGH VOLTAGE POWER SUPPLY MI-11 FOR  PD-3 UNIT

Manufactured in EI, Niš, Serbia

SOURCE: DUBRAVKO 9A6NNS, BRANKO 9A6AQK, Sava dump, Sesvete





HOMEBREW HF TUBE TRANSMITTER 50W  3,5-28 MHz

Build by 9A9DR

SOURCE: Dubravko Rogale





U.S. ARMY WW2 TRANSMITTER   BC-191-D

200 kHZ - 12.5 MHz,  year 1942

SOURCE: Krešimir Jesteršabec




AC POWER SUPPLY  RA-34  FOR BC-191 TRANSMITTER

3-6,67 MHz,  year 1942

SOURCE: Krešimir Jesteršabec





BRITISH WW2 SPY RADIO STATION   AP 5

Made by British Special Operations Executive SOE, year 1942-1944

2 - 16 MHz,  8 - 12 W

SOURCE: Krešimir Jesteršabec





SOVIET WW2 SPY RADIO STATION   V-100-A

3 -7  MHz,  15 W year 1942-1945

SOURCE: Zlatan Ribić





SOVIET WW2 S.W. RECEIVER  RSI-4T  FOR T-34 TANKS

3,7 - 5,8 MHz, year 1942-1944

SOURCE: Krešimir Jesteršabec





U.S. ARMY WW2 REMOTE CONTROL UNIT RM-29-A

Made by Crosley Corporation, Cincinnati, Ohio, USA

SOURCE: Krešimir Jesteršabec
