OSCILLOSCOPES



KAKO SU SE SAKUPLJALI OSCILOSKOPI ?

Većina osciloskopa iz zbirke je donirana ili je pak kupljena povrlo prihvatljivim i  razumnim cijenama od prijatelja radioamatera ili drugih poznanika koji znaju za moj hobi skupljanja starih vojnih radiouređaja i stare mjerne tehnike.

No, ima i još jedan važan izvor, a to su tzv. buvljaci. Njih ima više vrsta: na raznim okupljanjima radioamatera na Jarunu u Zagrebu, Friedrichhafenu u Njemačkoj, Hamfestima, klupskim buvljacima, poznati buvljak starina na Britancu, internetske aukcije i oglasnici. Najpopularniji, najpoznatiji i najbolji je buvljak Jakuševac ili bivši Hrelić. Na njemu se uz malo sreće, ako se redovito obilazi nedjeljom i srijedom, može na štošta naletjeti.

Evo primjera: samo rijetko izostanem s Jakuševca tako da u prosjeku jednom u par mjeseci izostanem uz valjan razlog, kao što sam izostao 19. 12. 2010. kad sam vozio mamu u liječilište Topusko na rehabilitaciju. Međutim, moji prijatelji i stalni posjetitelji, Krešo 9A3DBC, Ron 9A3JR, Ivica 9A3AWD i Toni 9A6RPQ su taj dan, u tri različite grupe, pronašli ponudu od  čak dva tzv. lampaška osciloskopa što je izuzetna rijetkost. Sve tri grupe su mi mobitelom javile za taj izniman događaj, ali prodavač je tražio čak 250 i 200 eura po komadu, uz obrazloženje da on dobro zna što se na Internetu traži, hi. Toni je čak snimio gornju sliku i poslao mi ju mailom isti dan. U prvom redu desno je Iskrin MA 4001, a u drugom redu lijevo Cossor 1035. Zbog neopravdane i stravično visoke cijene i užasno lošeg stanja osciloskopi naravno nisu prodani.

Od tada sam svaki puta bio na Jakuševcu srijedom i nedjeljom po onim žestokim smrzavicama, ali žuti hrđavi kombi i prodavač s osciloskopima kao da je u zemlju propao. Nikog nigdje. Sve do nedjelje 9.1.2011. kad je iznenada zatoplilo, Ivica javlja da ima u bunkeru jedan osciloskop za mene. Veselo hitam „Ilicom“ na Jakuševcu prema njemu i usput, na desnoj strani „Ilice“ ugledam Cossora. Pošto je? 150 kn !!! Bez cjenkanja (što je uvijek mali ritual) plaćam, odnosim ga uz pomoć Martina u svoj auto i hitam ponovo Ivici. U bunkeru ona tražena Iskra, cijena 200 kn !!! To je znači to. Ulovili smo dva zapuštena prljava dragulja iz 1948. i 1956. godine. Veselo kući, pa prvo temeljito čišćenje bar do faze da se može primiti u ruke i početi s ispitivanjem. Nakon čišćenja osciloskopi pomalo dobivaju svoj stari šarm. Vidljivo je da je Cossor otvaran, ali Iskra ima još tvorničku blombu. Idemo ih priključiti na napon.



A. C. Cossor Ltd, Model 1035 Iskra MA 4001



Uključuje se Krešin autransformator, prva je redu Iskra, polagano se diže napon da ne eksplodiraju elektroliti, lampica na prednjoj ploči svjetli sve jače! Čeka se par minuta da se zagriju lampe, ali nema slike. Okreću se svi gumbi i prvo razočaranje, osciloskop ne radi. Vjerojatno onda ne radi ni Cossor jer je znatno stariji, otvaran, u lošijem stanju. Kad ono drugo iznenađenje – Cossor radi !

Popravak Iskre je potrajao od nedjelje do petka, cijeli tjedan sam kod poznatih i po internetu tražio sheme, svakodnevno su se ispitivali i mijenjali  istrunuli papirnati kondenzatori, izgorjeli otpornici i stari ugljeni otpornici koji su promijenili svoje vrijednosti. Sve su to bile komponente koje je Iskra tek bila počela proizvoditi iza drugog svjetskog rata, prije više od 60 godina, bez ikakvog prethodnog iskustva. Promjenjena su tri probijena kondenzatora, jedan izgorjeli otpornik i dva otpornika koja su promijenila vrijednosti. I u petak, šesti dan rada, na ekranu se napokon pojavila slika kalibracijskog signala, zahvaljujući Krešinim visokonaponskim blok kondenzatorima. No, niti danas još nemam objavljene sheme ni tiskanih servisnih podataka za taj osciloskop. Kvarovi su otklanjani postojećim znanjem, iskustvom i intuicijom. Osciloskop je na kraju testiran, sastavljen, uslikan i odložen među ostale primjerke, a obadva primjerka možete vidjeti u galeriji slika.



Na sličan način su se skupljali, čistili, testirali i popravljali i ostali osciloskopi iz zbirke. Po neke se je putovalo i u razne krajeve Hrvatske, no o tome na drugom mjestu.





CATHODE RAY 20 kHz OSCILLOSCOPE  PHILIPS GM 3155

Manufactured by "Philips“, Netherland, Year 1937

SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 28-30. 6. 2013.)





DUAL TRACE CATHODE RAY OSCILLOSCOPE   COSSOR  1035

Manufactured in A.C. Cossor Ltd, London, England, 1947

DATA: Dual Trace Cathode Ray Tube,  5MHz Bandwidth,  23 Valves, Size  (42cm by 30.5cm by 51cm)

SCREEN DIAMETER: 90 mm

POWER SUPPLY: 220 VAC

 SET: VACUUM TUBES

SOURCE:   Dubravko Rogale, 9A9DR, Jakuševac, 9. 1. 2011.





CATHODE RAY 500 kHz OSCILLOSCOPE  OS-57/USM-38  U.S. NAVY

Manufactured by "Trad Electronics Corp“, New Jersey, early 1950.

VACUUM TUBE  SET

POWER SUPPLY:                 115 VAC

FREQUENCY:                       10 Hz – 50 kHz

INPUT SENSITIVITY:        1 V/inch



SOURCEKrešo Lerota, 9A3DBC





CATHODE RAY 70  kHz   FUNKE 624 OCZILLOGRAFF

Manufactured by "Max Funke", Germany, 1952.

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 2 Hz – 70 kHz

INPUT SENSITIVITY: 0;1 V/cm – 1000 V/cm

SOURCE Marijan Rečić,  9A2C,  20. 10. 2012.





CATHODE RAY 20 kHz OSCILLOSCOPE    PHILIPS   GM5655

Manufactured by "philips", Netherland, 1953.

FREQUENCY: 5 Hz - 5 kHz CONT. IN 4 RANGES

INPUT VOLTAGE: 0 - 300 Vpp

SCREEN DIAMETER: 70 mm

POWER SUPPLY: 220 VAC

SET: VACUUM TUBES

SOURCE:   Dalibor Strnak, 34308 Jakšić, via Toni Oreč, (Hr. sci. elektronika), 28. 10. 2011.





CATHODE RAY 30 kHz OSCILLOSCOPE    RIZ  OS-155

Manufactured by "Radio industrija Zagreb- RIZ", Zagreb, Croatia, 1955.

FREQUENCY: 30 Hz - 30 kHz CONT. IN 4 RANGES

INPUT VOLTAGE: 0 - 300 Vpp

SCREEN DIAMETER: 65 mm

POWER SUPPLY:  220 VAC

 SET: VACUUM TUBES



SOURCEBožo Kranjec Mikra, Gračani, Zagreb, 9.12.2011.





CATHODE RAY 50 kHz OSCILLOSCOPE    RIZ  OS-157A

Manufactured by "Radio industrija Zagreb- RIZ", Zagreb, Croatia, 1957.

FREQUENCY: 50 Hz - 100 kHz CONT. IN 4 RANGES

INPUT VOLTAGE: 0 - 300 Vpp

SCREEN DIAMETER: 65 mm

POWER SUPPLY: 220 VAC

 SET: VACUUM TUBES

 SOURCE: Branko Filipčić, 9A5ABB,  Krešo Lerota





CATHODE RAY 500 kHz TUBE OSCILLOSCOPE    TYP OK-14 M66

Manufactured by "Radiotechnika", Wroclaw, Poland

FREQUENCY: 2 Hz - 500 kHz CONT. IN 9 RANGES

INPUT VOLTAGE: 50 - 150 Vpp

POWER SUPPLY: 220 VAC SET:

VACUUM TUBE SET



                   SOURCE:   Dubravko Rogale, 9A9DR (Jakuševac) 14. 8.2011. (100 kn)





CATHODE RAY 400 kHz OSCILLOSCOPE  TPW  RFT

Manufactured by "RFT", Former East Germany

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 400 kHz

INPUT SENSITIVITY: 0,1 V – 300 V

SOURCE: Prof. dr.sc. Siniša Fajt, 7. 3. 2012.





CATHODE RAY OSCILLOSCOPE  Servotest Orion

Manufactured by "Orion", Hungary

SOURCE:   Jure Šlat, 9A7KSJ ,Ogulin





CATHODE RAY OSCILLOSCOPE  Servotest Orion TYPE 1931/B

Manufactured by "Orion", Hungary

SOURCEDubravko Rogale, 9A9DR (Via Njuškalo, Arni Roglić)





CATHODE RAY 60 kHz OSCILLOSCOPE    GRUNDIG G4

Manufactured by "Grundig", Germany, 1958.

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 60 kHz

INPUT SENSITIVITY: 1 V – 1000 V

SOURCE: Dubravko Rogale, 9A9DR (Jakuševac 18. 3. 2012.)





CATHODE RAY 100 kHz OSCILLOSCOPE    GRUNDIG G4

Manufactured by "Grundig", Germany, 1964.

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 100 kHz

INPUT SENSITIVITY: 30 mV – 100 V/cm

SOURCE: Tomislav Kordaso, 9A5TT, Trešnjevka, 5. 6. 2012.





CATHODE RAY 100 kHz OSCILLOSCOPE    HEATHKIT  OL-1

Manufactured by "HEATH COMPANY", Benton Harbour, Michigan, USA, 1955.

FREQUENCY: 50 Hz - 200 kHz CONT. IN 5 RANGES

INPUT VOLTAGE: 0 - 50 Vpp

SCREEN DIAMETER: 70 mm

 POWER SUPPLY:  220 VAC SET:

VACUUM TUBE SET



SOURCE:   Stjepan Krkač,  9A2RV







CATHODE RAY 5 MHz OSCILLOSCOPE     HEATHKIT  O-10

Manufactured by "HEATH COMPANY", Benton Harbour, Michigan, USA, 1955.

O-10 Oscilloscope, 11 tubes. Vertical frequency response within 5db from 5 Hz to 5 mHz.
 New sweep circuit,linear from 20 Hz to more than 500,000 Hz.
 Built-in 1-v peak-to-peak reference for calibrating plastic CRT faceplate.
0.025v/inch deflection sensitivity.

SOURCE:  Nikola Subotičanec, Križevci, 23. 1. 2011.





CATHODE RAY 5 MHz OSCILLOSCOPE     HEATHKIT  O-12

Manufactured by "HEATH COMPANY", Benton Harbour, Michigan, USA, 1958.

O-12 5 Inch Scope. Vertical frequency response:  3 Hz to 5 mHz,
 plus or minus 1.5db--5db without extra switching.
Sweep:  10 Hz to more than 500 kHz in 5 steps. 1-v calibrator. 11 tubes,
including 5UP1 CRT. Horiz. amp response:  Plus or minus 1db from 1 Hz to 200 kHz. Horiz. sensitivity:  0.3-v RMS/inch.


SOURCE:  Dubravko Rogale, 9A9DR (Jakuševac) 6. 4.2011. (50 kn)





CATHODE RAY 500 kHz OSCILLOSCOPE      HEATHKIT  IO-18U

Manufactured by "HEATH COMPANY", Gloucester, United Kingdom 1968.

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 500 kHz

INPUT SENSITIVITY: 30 mV/cm –peak to peak at 1 kHz (4,5 MHz bandwidth)

 SOURCE:  BRANKO PALINIĆ





CATHODE RAY 500 kHz OSCILLOSCOPE     HEATHKIT  IO-18

Manufactured by "HEATH COMPANY", Benton Harbour, Michigan, USA, 1968.

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 500 kHz

INPUT SENSITIVITY: 30 mV/cm –peak to peak at 1 kHz (4,5 MHz bandwidth)

 SOURCE:  Dubravko Rogale, 9A9DR (Jakuševac)







CATHODE RAY 200 kHz TUBE OSCILLOSCOPE  C1-5

Manufactured in former USSR

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 200 kHz

INPUT SENSITIVITY: 1 V – 500 V

 SOURCEFranjo, 9A7BHL, Ludbreg, 17. 12. 2010.





CATHODE RAY 100 kHz TUBE OSCILLOSCOPE   EICO 460

Manufactured in USA

VACUUM TUBE  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 100 kHz

INPUT SENSITIVITY: 1 V – 1000 V

 SOURCEDubravko, 9A9DR, Njuškalo 8. 4. 2011.





DUAL TRACE OSCILLOSCOPE   GRUNDIG JO 20/13

SOURCE: Hr. sci. elektronika via Toni Oreč





CATHODE RAY 50 kHz OSCILLOSCOPE   ISKRA NE 0070

Manufactured by "Iskra", Slovenia, early 1950 (first Iskra oscilloscope)

FREQUENCY: 5 Hz - 50 kHz CONT. IN 4 RANGES

INPUT VOLTAGE: 0 - 500 Vpp

SCREEN DIAMETER: 65 mm

 POWER SUPPLY: 220 VAC

SET: VACUUM TUBES

 SOURCE:   Matej Kodrič, 4000 Kranj, 1. 12. 2014.





CATHODE RAY 50 kHz OSCILLOSCOPE   ISKRA MA 4005

Manufactured by "Iskra", Slovenia, early 1950 (improved NE 0070)

FREQUENCY: 5 Hz - 50 kHz CONT. IN 4 RANGES

INPUT VOLTAGE: 0 - 500 Vpp

SCREEN DIAMETER: 65 mm

POWER SUPPLY: 220 VAC

 SET: VACUUM TUBES

SOURCE:   Boštjančič Zvonko, Župančićeva 31, 4000 Kranj, 22. 12. 2010.





CATHODE RAY 100 kHz OSCILLOSCOPE   MA 4001

Manufactured by "Industrija za elektrozveze", Ljubljana, Slovenia, 1955.

FREQUENCY:  1 Hz - 100 kHz CONT. IN 5 RANGES

INPUT VOLTAGE: 25 mV/cm - 25 V/cm

SCREEN DIAMETER: 70 mm

POWER SUPPLY:  220 VAC

 SET:  VACUUM TUBES

 SOURCE:   Branko Habuš, 9A5ABH, 16. 9. 2014.





CATHODE RAY 100 kHz OSCILLOSCOPE   MA 4001

Manufactured by "Industrija za elektrozveze", Ljubljana, Slovenia, 1956.

Improved IEV 1955 (Prevesnik/Časovna baza, buton 100mV, BNC connectors)

 FREQUENCY:  1 Hz - 100 kHz CONT. IN 5 RANGES

INPUT VOLTAGE: 25 mV/cm - 25 V/cm

SCREEN DIAMETER: 70 mm

POWER SUPPLY: 220 VAC

 SET:  VACUUM TUBES

SOURCE:   Ivica Dimnjaković, 9A3AWD, Jakuševac 9. 1. 2011.





CATHODE RAY 200 kHz OSCILLOSCOPE   IEV MA 4040

Manufactured by "IEV", Ljubljana, Slovenia, 1956.

FREQUENCY: 1 Hz - 200 kHz CONT. IN 5 RANGES

INPUT VOLTAGE: 10 mV/cm - 20 V/cm

SCREEN DIAMETER: 70 mm

POWER SUPPLY: 220 VAC

 SET:  VACUUM TUBES

 SOURCE:   Dejan Jeraj,  Blatna Brezovica, Vrhnika, Slovenia, 7. 12. 2011.





CATHODE RAY 200 kHz OSCILLOSCOPE   ISKRA MA 4040

Manufactured by "Iskra", Slovenia, 1957.



FREQUENCY: 1 Hz - 200 kHz CONT. IN 5 RANGES

INPUT VOLTAGE: 10 mV/cm - 20 V/cm

SCREEN DIAMETER: 70 mm

POWER SUPPLY: 220 VAC

 SET:  VACUUM TUBES

 SOURCE:   Zlatko Mumlek, Jakuševac  9. 10. 2011.





CATHODE RAY 50 kHz OSCILLOSCOPE   ISKRA MA 4060

Manufactured by "Iskra", Slovenia, 1968.



FREQUENCY: 1 Hz - 50 kHz CONT. IN 5 RANGES

INPUT VOLTAGE:  50 mV/cm - 5 V/cm

SCREEN DIAMETER: 160 mm

SET: VACUUM TUBES

 SOURCE:   Prof. Dubravko Prokop, dipl. ing.  27. 12. 2011.





CATHODE RAY 50 kHz OSCILLOSCOPE   ISKRA MA 4061

Manufactured by "Iskra", Slovenia, 1970.



FREQUENCY: 1 Hz - 50 kHz CONT. IN 5 RANGES

INPUT VOLTAGE: 50 mV/cm - 5 V/cm

SCREEN DIAMETER: 160 mm

SET:  VACUUM TUBES

SOURCE:   Mr. sc. Željko Knezić, dipl. ing.





CATHODE RAY 20 kHz OSCILLOSCOPE  ISKRA MA 4006

Manufactured by "Iskra", Slovenia



VACUUM TUBE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  5s/cm to 0,5 μs/cm

SENSITIVITY:  5 mV – 20 V/cm

 SOURCE: Prof. dr. sc. Jelka Geršak, 10. 12. 2010. (Bolha.com)





CATHODE RAY 50 kHz OSCILLOSCOPE  ISKRA MA 4003

Manufactured by "Iskra", Slovenia,1971.



VACUUM TUBE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0 – 50 kHz Time base

SENSITIVITY:  0,1V – 10 V/cm

SOURCE: Mihael 9A3CFM i Zdravko Frenki Franceković, 5. 2. 2011.





CATHODE RAY 50 kHz OSCILLOSCOPE  ISKRA MA 4003/2

Manufactured by "Iskra", Slovenia,1973.

VACUUM TUBE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: 0 – 50 kHz Time base

SENSITIVITY: 0,1V – 10 V/cm

 SOURCE: Zlatko Šrajber, Jakuševac, 6. 2. 2011.





CATHODE RAY 50 kHz OSCILLOSCOPE    IMETRON S 777

Manufactured in Italy

2 Tubes !!!

 SOURCE:  9A9DR, Dubravko, Jakuševac,  19. 1. 2011.





CATHODE RAY 10 MHz OSCILLOSCOPE      PHILIPS   PM 3200 X

Manufactured by "Philips“, Netherland, 1969.



VACUUM TUBE & TRANSISTOR  SET

POWER SUPPLY: 220 VAC

FREQUENCY: 0  -  10  MHz

INPUT SENSITIVITY:  2 mV/cm to 50 V/cm

 SOURCE:  Dubravko Rogale, 9A9DR (Plavi oglasnik)





DUAL TRACE 10 MHz OSCILLOSCOPE    PHILIPS  PM 3230

Manufactured by "Philips“, Netherland, 1968

VACUUM TUBE & TRANSISTOR  SET , 85 W, 11 kg

POWER SUPPLY: 220 VAC

FREQUENCY: 0  -  10  MHz

INPUT SENSITIVITY: 2 mV/cm to 50 V/cm

 SOURCE:  Zlatko Šrajber, 18. 1. 2011.





CATHODE RAY 25 MHz OSCILLOSCOPE      PHILIPS   PM 3226

Manufactured by "Philips“, Netherland

TRANSISTOR SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 25 MHz

SENSITIVITY:  0,02 –10 V/cm

 SOURCE:  Krešo Lerota, 9A3DBC





CATHODE RAY 25 MHz OSCILLOSCOPE      PHILIPS   PM 3260 E

Manufactured by "Philips“, Netherland

 TRANSISTOR & SPEC. CHIP-SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 60 MHz

SENSITIVITY:  0,05 –2 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Jakuševac, 22. 1. 2012., Mladen)





DUAL BEAM  10 MHz OSCILLOSCOPE    OSCILLAR M911

Manufactured in Siemens, Germany

VACUUM & TRANSISTOR TUBE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  1 s/cm – 0,2 µs/cm

SENSITIVITY:  50 mV – 50 V/cm

 SOURCE:  Franjo Wolšperger via Dragan Visković 29. 3. 2012.





DUAL TRACE CATHODE RAY 30 MHz OSCILLOSCOPE   TEKTRONIX  310A

Manufactured in Tektronix, Portland, Oregon, USA, 1958.



VACUUM TUBE SET (30 Tubes)

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 4 MHz

SENSITIVITY:  10 mV – 50 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Jakuševac, 6. 7. 2011., 250 kn!)





DUAL BEAM  1 MHz OSCILLOSCOPE    TEKTRONIX  502A

Manufactured in Tektronix, Portland, Oregon, USA, 1960.



VACUUM TUBE SET (designed for biomedical research)

 POWER SUPPLY: 220 VAC

FREQUENCY:  DC – 1 MHz

SENSITIVITY:  100 μV – 20 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Jakuševac, Marko)





MONO BEAM  10 MHz OSCILLOSCOPE    TEKTRONIX  515A

Manufactured in Tektronix, Portland, Oregon, USA, 1960.



VACUUM TUBE SET (designed for biomedical research)

 POWER SUPPLY: 220 VAC

FREQUENCY: 2 s/cm – 0,2 μscm

SENSITIVITY: 50 mV – 20 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 24. 6. 2012.)





DUAL BEAM  15 MHz OSCILLOSCOPE    TEKTRONIX  531A

Manufactured in Tektronix, Portland, Oregon, USA, 1959.

VACUUM TUBE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: DC – 15 MHz

SENSITIVITY: 0,001 – 50 V/cm

 SOURCE:   Matej Kodrič, 4000 Kranj, 23. 12. 2014.





DUAL TRACE CATHODE RAY 30 MHz OSCILLOSCOPE   TEKTRONIX  545B

Manufactured in Tektronix, Portland, Oregon, USA, 1959.

VACUUM TUBE SET (90 tubes)

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 30 MHz

SENSITIVITY: 0,05 – 20 V/cm

 SOURCE: IVICA RUKLIĆ, 9A3ARI





DUAL TRACE CATHODE RAY 15 MHz OSCILLOSCOPE   TEKTRONIX  561A

Manufactured in Tektronix, Portland, Oregon, USA



SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 28-30. 6. 2013.)





DUAL TRACE CATHODE RAY STORAGE OSCILLOSCOPE   TEKTRONIX  564

Manufactured in Tektronix, Portland, Oregon, USA

SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 27-29. 6. 2014.)





DUAL TRACE CATHODE RAY 15 MHz OSCILLOSCOPE   TEKTRONIX  564B

Manufactured in Tektronix, Portland, Oregon, USA

SOURCE: Dubravko Rogale, Njuškalo.hr





DUAL TRACE CATHODE RAY 15 MHz OSCILLOSCOPE   TEKTRONIX  422

Manufactured in Tektronix, Portland, Oregon, USA



VACUUM TUBE & TRANSISTOR SET

 POWER SUPPLY:  220 VAC

FREQUENCY: DC – 15 MHz

SENSITIVITY:  0,1 –20 V/cm

 SOURCE:  :  Dr. sc. Ronald Eisenwagner – Ron   9A5JR / OE3REB





DUAL TRACE CATHODE RAY 50 MHz OSCILLOSCOPE   TEKTRONIX  453

Manufactured in Tektronix, Portland, Oregon, USA



VACUUM TUBE & TRANSISTOR SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 50 MHz

SENSITIVITY:  0,05 –10 V/cm

 SOURCE:  Krešo Lerota





DUAL TRACE CATHODE RAY 150 MHz OSCILLOSCOPE   TEKTRONIX  454

Manufactured in Tektronix, Portland, Oregon, USA



VACUUM TUBE & TRANSISTOR SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 150 MHz

SENSITIVITY: 0,05 – 10 V/cm

 SOURCE:  Mario Dumitrov, 9A3ADM





SINGLE TRACE CATHODE RAY 5 MHz OSCILLOSCOPE   TEKTRONIX  221

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY: 220 VAC & 10 NiCad Bateries

FREQUENCY: DC – 5 MHz

SENSITIVITY:  0,05 –100 V/cm

 SOURCE:  Dr. Ronald Eisenwagner via Krešo Lerota





DUAL TRACE 10 MHz STORAGE OSCILLOSCOPE   TEKTRONIX  314

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY:  220 VAC, 12 VDC, 24 VDC

FREQUENCY:  DC – 10 MHz

SENSITIVITY: 1 mV –10 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 26. 6. 2011.)





DUAL TRACE    AN/USM-425(V)1 OSCILLOSCOPE   TEKTRONIX

Manufactured in Tektronix, Beaverton, Oregon, USA

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  DC – 100 MHz

SENSITIVITY:  0,05 – 5 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 26. 6. 2011.)





DUAL TRACE CATHODE RAY 100 MHz OSCILLOSCOPE   TEKTRONIX  465

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  DC – 100 MHz

SENSITIVITY:  0,05 – 5 V/cm

 SOURCE:  Krešo Lerota 9A3DBC, Ivica Dimnjaković 9A3AWD,

 Jakuševac, 4. 9 .2011, (130 kn, bad condition); Mr. sc. Zdenko Ljubić i

Dr. sc. Željko Knezić, Zagreb, 26. 5. 2014. (0 kn, great condition)





DUAL TRACE CATHODE RAY 100 MHz OSCILLOSCOPE   TEKTRONIX  465M

Manufactured in Tektronix, Portland, Oregon, USA

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 100 MHz

SENSITIVITY: 0,05 – 5 V/cm

 SOURCE:  Zvonko Bocak, 9A6KGG





DUAL TRACE CATHODE RAY 200 MHz OSCILLOSCOPE   TEKTRONIX  475 WITH 3 ½  DIGITAL MULTIMETER   DM44

Manufactured in Tektronix, Portland, Oregon, USA

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 200 MHz

SENSITIVITY: 0,05 –5 V/cm

 SOURCE: Zvonko Bocak, 9A6KGG





DUAL TRACE CATHODE RAY 250 MHz OSCILLOSCOPE   TEKTRONIX  475A

Manufactured in Tektronix, Portland, Oregon, USA

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: DC – 250 MHz

SENSITIVITY:  0,05 –10 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichshafen, )





DUAL TRACE CATHODE RAY 20 MHz OSCILLOSCOPE   TEKTRONIX  2205

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  DC – 20 MHz

SENSITIVITY:  0,05 –2 V/cm

 SOURCE:  Berislav Mioković, 9A1BM





DIGITAL STORAGE 100 MHz OSCILLOSCOPE   TEKTRONIX  2230

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 100 MHz

SENSITIVITY:  0,02 – 50 V/cm

 SOURCE: Martin Švaco, 9A2JK





DIGITAL STORAGE 100 MHz OSCILLOSCOPE   TEKTRONIX  2232

Manufactured in Tektronix, Portland, Oregon, USA



SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 28-30. 6. 2013.)





DUAL TRACE CATHODE RAY 20 MHz OSCILLOSCOPE   TEKTRONIX  2235

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 100 MHz

SENSITIVITY: 2 mV – 5 V/cm

 SOURCE: Krešo Lerota 9A3DBC, Jakuševac/Friedrichaffen 18. 9. 2011.





DUAL TRACE CATHODE RAY 100 MHz OSCILLOSCOPE   TEKTRONIX  2335

Manufactured in Tektronix, Portland, Oregon, USA

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  DC – 100 MHz

SENSITIVITY:  0,05 – 5 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichshafen)





DUAL TRACE CATHODE RAY 100 MHz OSCILLOSCOPE   TEKTRONIX  7623

Manufactured in Tektronix, Portland, Oregon, USA

SOLID STATE SET

POWER SUPPLY: 220 VAC

FREQUENCY:  DC – 100 MHz

SENSITIVITY: 0,05 –5 V/cm

 SOURCE:  Duje Blašković 9A7DBM, Split, 23. 12. 2010.)





DUAL TRACE CATHODE RAY 100 MHz OSCILLOSCOPE   TEKTRONIX  7623A

Manufactured in Tektronix, Portland, Oregon, USA



SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  DC – 100 MHz

SENSITIVITY: 0,05 –5 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Jakuševac)





DUAL TRACE OSCILLOSCOPE   TEKTRONIX  5103N

Manufactured in Tektronix, Portland, Oregon, USA

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 100 MHz

SENSITIVITY: 0,05 –5 V/cm

 SOURCE: Branko Runkas 9A6AQK, Jarun Hamfest 8. 9. 2012.





DUAL TRACE OSCILLOSCOPE   HEWLET PACKARD  HP 1742A

Manufactured in Hewlet packard, USA

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 100 MHz

SENSITIVITY: 0,05 –20 V/cm

 SOURCE:  Dr. sc. Željko Knezić, Jakuševac, 16. 9. 2012.





CATHODE RAY 1 MHz OSCILLOSCOPE   TELEQUIPMENT  S51A

Manufactured by "Telequipment", England, 1960-67.

VACUUM TUBE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: 1 Hz – 1 MHz

SENSITIVITY:  100 mV – 50 V/cm

 SOURCE:  Berislav Mioković, 9A1BM





CATHODE RAY 1 MHz OSCILLOSCOPE   TELEQUIPMENT  S51B

Manufactured by "Telequipment", England, 1960-67.

VACUUM TUBE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 1 Hz – 1 MHz

SENSITIVITY: 100 mV – 50 V/cm

 SOURCE:   Mr. sc. Željko Knezić, dipl. ing.





CATHODE RAY 5 MHz OSCILLOSCOPE   TELEQUIPMENT  S54A

Manufactured by "Telequipment", England

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  1 Hz – 2 MHz

SENSITIVITY:  10 mV – 50 V/cm

 SOURCE: 9A6RPQ, Antun Oreč,  9A2HM, Krešo Bišćan





CATHODE RAY 10 MHz OSCILLOSCOPE   TELEQUIPMENT  D54

Manufactured by "Telequipment", England

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 1 Hz – 10 MHz

SENSITIVITY:  10 mV – 50 V/cm

    SOURCE:   Stjepan Krkač,  9A2RV





CATHODE RAY 10 MHz OSCILLOSCOPE   TELEQUIPMENT  S61

Manufactured by "Telequipment", England

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 1 Hz – 10 MHz

SENSITIVITY: 10 mV – 50 V/cm

 SOURCE:   Mr. sc. Željko Knezić, dipl. ing.





CATHODE RAY OSCILLOSCOPE NORDMENDE UO 963

Manufactured by "Nordmende electronic", Germany

VACUUM TUBE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 35 Hz - 500 kHz

SENSITIVITY: 20 mV – 10 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 26. 6. 2011.)





CATHODE RAY OSCILLOSCOPE NORDMENDE TO 368

Manufactured by "Nordmende electronic", Germany



SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  0,5s to 0,5 μs

SENSITIVITY:  50 mV – 20 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Jakuševac, 14. 11. 2010.)





DUAL TRACE CATHODE RAY OSCILLOSCOPE   TRS 455

Manufactured by "Tvornica računskih strojeva", Zagreb, Croatia, 1984

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  5s/cm to 0,1 μs/cm

SENSITIVITY:  10 mV – 20 V/cm

SOURCE: Dubravko Rogale, 9A9DR (Njuškalo, Osijek, 10. 11. 2010.)





SINGLE TRACE CATHODE RAY 10 MHz OSCILLOSCOPE  ISKRA MA 4041

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  0 – 10 MHz

SENSITIVITY:  10 mV – 5 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Jakuševac, 11. 9. 2011.) via Zlatko Šrajber Antena





SINGLE TRACE CATHODE RAY 10 MHz OSCILLOSCOPE  ISKRA MA 4042

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  0 – 10 MHz

SENSITIVITY: 10 mV – 5 V/cm

 SOURCE: Ivica Jurić, Trnovčica, via njuškalo.hr





DUAL TRACE CATHODE RAY15 MHz OSCILLOSCOPE  ISKRA MA 4048

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  5s/cm to 0,5 μs/cm

SENSITIVITY:   5 mV – 20 V/cm

SOURCE:   Marijan Neralić, Ogulin, 1. 7. 2011.





DUAL TRACE CATHODE RAY 20 MHz OSCILLOSCOPE  ISKRA MA 4049

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  5s/cm to 0,5 μs/cm

SENSITIVITY: 5 mV – 20 V/cm

SOURCE:  Duje Blašković 9A7DBM, Split, 29. 11. 2010.





DUAL TRACE CATHODE RAY 20 MHz OSCILLOSCOPE  ISKRA MA 4070

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY:  0,5s/cm to 0,5 μs/cm

SENSITIVITY:  5 mV – 20 V/cm

 SOURCE: Duje Blašković, 9A7DBM, Split, 23. 12. 2010.





DUAL TRACE  100 MHz OSCILLOSCOPE  ISKRA BM 566

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  0,5s/cm to 0,05 μs/cm

SENSITIVITY:  10 mV – 5 V/cm

 SOURCE: Haban Rade, Žitnjak, II Radnički put 11, 23. 9. 2012.

Njuškalo via Toni Oreč, 9A6RPQ





LCD DIGITAL OSCILLOSCOPE    ISKRASCOPE LCD

Manufactured by "Iskra", Slovenia



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: DC – 100 MHz

SENSITIVITY: 0,05 –10 V/cm



SOURCE:   Branko Filipčić, 9A5ABB





CATHODE RAY 500 kHz OSCILLOSCOPE   HAMEG HM 107-2

Manufactured by "Hameg", Germany



VACUUM TUBE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 160 kHz Time base

SENSITIVITY: 20 mV – 5 V/cm

 SOURCE: Marinko Šantaj, Veliki Bukovec, Ludbreg 22. 9. 2012.

Njuškalo via Toni Oreč,  9A6RPQ





CATHODE RAY 500 kHz OSCILLOSCOPE   HAMEG HM 107-3

Manufactured by "Hameg", Germany



VACUUM TUBE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 500 kHz Time base

SENSITIVITY: 100 mV – 5 V/cm

SOURCE:  Dr. sc. Željko Knezić. Jakuševac





CATHODE RAY 500 kHz OSCILLOSCOPE   HAMEG HM 107-5

Manufactured by "Hameg", Germany

VACUUM TUBE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 10 Hz – 500 kHz Time base

SENSITIVITY: 100 mV – 5 V/cm

 SOURCE: Zlatko Šrajber, 23.1. 2011. Jakuševac





CATHODE RAY 500 kHz OSCILLOSCOPE   HAMEG HM 108

Manufactured by "Hameg", Germany, 1964.

VACUUM TUBE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: 10 Hz – 500 kHz Time base

SENSITIVITY:  50 mV – 30 V/cm

 SOURCE: Zlatko Šrajber, 24.9. 2012.  Getro





CATHODE RAY OSCILLOSCOPE   HAMEG HM 203-4

Manufactured by "Hameg", Germany

TIME BASE:0,2 s/cm - 0,5 μs/cm

FREQUENCY: 20 MHz

INPUT VOLTAGE: 20 mV/cm - 5V/cm

SCREEN DIMENSION:100 x 80 mm

 POWER SUPPLY: 220 VAC

 SET:    SOLID STATE

 SOURCE:  9A9DR  Dubravko Rogale





CATHODE RAY DUAL TRACE OSCILLOSCOPE   HAMEG HM 203-6

Manufactured by "Hameg", Germany



TIME BASE: 0,2 s/cm - 0,5 μs/cm

FREQUENCY: 20 MHz

INPUT VOLTAGE: 20 mV/cm - 5V/cm

SCREEN DIMENSION: 100 x 80 mm

 POWER SUPPLY:  220 VAC

 SET:  SOLID STATE

 SOURCE:  : Prof. dr. sc. Jelka Geršak, 22. 12. 2010. Tehniška fakulteta Univerze v Mariboru





CATHODE RAY 500 kHz OSCILLOSCOPE   HAMEG HM 207-1

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: 10 Hz – 500 kHz Time base

SENSITIVITY: 50 mV – 30 V/cm

 SOURCE:  Nikola Subotičanec, 4. 2. 2011.  Dubrava





CATHODE RAY OSCILLOSCOPE   HAMEG HM 207-2

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: 10 Hz – 500 kHz Time base

SENSITIVITY:  50 mV – 30 V/cm

 SOURCE:  Nikola Subotičanec, Križevci, 23. 1. 2011.





CATHODE RAY OSCILLOSCOPE   HAMEG HM 307-3

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  0,2 s/cm to 0,5 μs/cm

SENSITIVITY: 5 mV – 20 V/cm

SOURCE:  Nikola Subotičanec, Križevci, 23. 1. 2011.





CATHODE RAY OSCILLOSCOPE   HAMEG HM 312-1

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 30 ms/cm – 0,3 μs/cm Time base

SENSITIVITY:  50 mV – 30 V/cm

 SOURCE:  Damir Malokos, Put dr. Ante Starčevića,  20207 Mlini, 6. 6. 2011.





DUAL TRACE 2 MHz OSCILLOSCOPE   HAMEG HM 312-6

Manufactured by "Hameg", Germany



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0,2 s/cm to 0,5 μs/cm

SENSITIVITY:  5 mV – 20 V/cm

 SOURCE:   Jure Šlat, 9A7KSJ, Ogulin,





DUAL TRACE 2 MHz OSCILLOSCOPE   HAMEG HM 412-1

Manufactured by "Hameg", Germany



SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0,2 s/cm to 0,5 μs/cm

SENSITIVITY:   5 mV – 20 V/cm

 SOURCE: Zlatko Šrajber, 20.1. 2011. Backyard of TTF





CATHODE RAY DUAL TRACE OSCILLOSCOPE   HAMEG HM 412-2

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0,2 s/cm to 0,5 μs/cm

SENSITIVITY: 5 mV – 20 V/cm

 SOURCE:  Vladimir Hervoj, Božidara Magovca, Zagreb,  23. 1. 2011. (Aukcije)





CATHODE RAY OSCILLOSCOPE   HAMEG HM 512-2

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY:  0,2 s/cm – 0,2 μs/cm Time base

SENSITIVITY: 5 mV – 20 V/cm

 SOURCE:   Marijan Neralić, Ogulin, 4. 6. 2011.





CATHODE RAY DUAL TRACE OSCILLOSCOPE   HAMEG HM 512-3

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0,2 s/cm – 0,2 μs/cm Time base

SENSITIVITY:  5 mV – 20 V/cm

 SOURCE:   Marijan Neralić, Ogulin, 1. 7. 2011.





CATHODE RAY 70 MHz OSCILLOSCOPE   HAMEG HM 705

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0,2 s/cm – 0,05 μs/cm Time base

SENSITIVITY:  5 mV – 20 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 26. 6. 2011.)





DUAL BEAM 50 MHz STORAGE OSCILLOSCOPE   HAMEG HM 812

Manufactured by "Hameg", Germany

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 0,5 s/cm – 0,1 μs/cm Time base

SENSITIVITY:  5 mV – 20 V/cm

SOURCE: Toni Oreč, 9A6RPQ, 10. 6. 2012.





CATHODE RAY OSCILLOSCOPE  EI  PO6

Manufactured by "Ei", Niš, Serbia



SOURCE:  9A2RV Stjepan Krkač i 9A5ABB Branko Filipčić

RK Brdovec  19. 1. 2011.





CATHODE RAY DUAL TRACE OSCILLOSCOPE   SE Labs  EM102D

Manufactured by "SE Labs", USA

SOURCE: Tino, Trešnjevka





CATHODE RAY 6 MHz OSCILLOSCOPE   CENTRAD 175 P10

Manufactured by "Centrad Annecy", France, 1966.



SOURCE:   Marijan Neralić, Ogulin, 2. 4. 2011.





CATHODE RAY DUAL TRACE OSCILLOSCOPE   PANTEC 4D 10

Manufactured by "Pantec", Italy



SOURCE:   Marijan Neralić, Ogulin, 2. 4. 2011.





CATHODE RAY DUAL TRACE OSCILLOSCOPE   SIMPSON 455T

Manufactured by "Simpson", USA

SOURCE:   Miha, 9A2XI, 10. 4. 2011.





CATHODE RAY DUAL TRACE OSCILLOSCOPE   GRUNDIG  MO 50

Manufactured by "GRUNDIG Electronic", West Germany



SOURCE:   Dubravko Petrunić, 9A7PPD, Duga Resa, 26. 10. 2011. (Njuškalo)





DUAL TRACE 20 MHz OSCILLOSCOPE   VOLTCRAFT 2040

Manufactured by "Voltcraft", West Germany

SOLID STATE SET

 POWER SUPPLY:  220 VAC

TIME BASE:   2 s/cm – 0,1 µs/cm

SENSITIVITY: 5 mV – 5 V/cm

SOURCE: 9A3AWD,  Ivica Dimnjaković, 25. 3. 2012.





DUAL TRACE 20 MHz OSCILLOSCOPE   LEADER LBO-506A

Manufactured by "Leader"

SOLID STATE SET

 POWER SUPPLY: 220 VAC

TIME BASE: 2 s/cm – 0,1 µs/cm

SENSITIVITY:  10 mV – 5 V/cm

SOURCE: Toni Oreč, 9A6RPQ.





CATHODE RAY OSCILLOSCOPE   C1-73

Manufactured by former USSR



SOLID STATE SET

POWER SUPPLY: 220 VAC

FREQUENCY:  50 ms – 0,05 µs/cm

SENSITIVITY: 10 mV – 20 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 24. 6. 2012.





CATHODE RAY OSCILLOSCOPE   C1-94

Manufactured by former USSR



SOURCE: 9A3AWD,  Ivica Dimnjaković, 10. 4. 2011.





CATHODE RAY OSCILLOSCOPE   C1-94/G

Manufactured by former USSR



SOURCE: 9A3AWD,  Ivica Dimnjaković, 15. 4. 2012.





CATHODE RAY 20 MHz OSCILLOSCOPE    C1-112A

Manufactured by former USSR



SOLID STATE SET

POWER SUPPLY: 220 VAC

FREQUENCY: 1 Hz – 20 MHz

SENSITIVITY:  5 mV – 5 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Njuškalo, 15. 2. 2012. Velika Gorica, Siniša)





DUAL TRACE OSCILLOSCOPE    C1-118

Manufactured in former USSR

SOLID STATE SET

 POWER SUPPLY: 220 VAC

FREQUENCY: 50 ms – 0.05 μs

SENSITIVITY:  5 mV – 10 V/cm

 SOURCE: Željko Knezić, Jakuševac, 16. 9. 2012.





CATHODE RAY OSCILLOSCOPE   H313

Manufactured in former USSR,  Year 1983.



SOLID STATE SET

 POWER SUPPLY:  220 VAC

FREQUENCY: 1 Hz – 2 MHz

SENSITIVITY:  1 mV – 20 V/cm

SOURCE: Zlatko Šrajber (Jarun 2010.)





CATHODE RAY OSCILLOSCOPE   N3017

Manufactured in former USSR,  Year 1983.

SOLID STATE SET

 POWER SUPPLY: 27 VDC

FREQUENCY: 0,5 s/cm – 0,01 ms/cm

SENSITIVITY: 20 mV – 10 V/cm

 SOURCE: Dubravko Rogale, 9A9DR (Friedrichafen, 24. 6. 2012.)





CATHODE RAY OSCILLOSCOPE   SAGA

Manufactured by former USSR



SOURCE:   Stjepan Krkač,  9A2RV





CATHODE RAY 2 MHz OSCILLOSCOPE  JSTZYC  J 2459

Manufactured by China?

SOURCE: Zlatko Šrajber





CATHODE RAY  MONITOR SCOPE   YO-100

Manufactured by Sommerkamp



SOURCE:  Krešo Lerota, 9A3DBC





ACTIVE FET PROBE FOR OSCILLOSCOPE   TEKTRONIX   P6045

Manufactured in Tektronix, Portland, Oregon, USA

 For oscilloscopes that come with a 1-megaohm input resistance.

Bandwidth of 300 megahertz at -3 decibels and a minimum bandwidth of 16 hertz at -3dB.

The probe's DC offset range is from -1 to +1 volt. The P6045 comes with probe gain settings of 1X, 10X and 100X.

SOURCE:  :  Dr. sc. Ronald Eisenwagner – Ron   9A5JR / OE3REB





OSCILLOSCOPES

7





OSCILLOSCOPES & ROSES





PLUG INN FOR TEKTRONIX OSCILLOSCOPES TYPE 2A63 DIFERENTIAL AMPLIFIER





PLUG INN FOR TEKTRONIX OSCILLOSCOPES TYPE 2B67 TIME BASE





PLUG INN FOR TEKTRONIX OSCILLOSCOPES TYPE 3A9 DIFERENTIAL AMPLIFIER





PLUG INN FOR TEKTRONIX OSCILLOSCOPES TYPE 3B3 TIME BASE



CATHODE RAY 100 kHz OSCILLOSCOPE  Type EO 1/7

Manufactured by "PGH", Former East Germany

SOURCE:  Dubravko Rogale, 9A9DR, FHN





CATHODE RAY OSCILLOSCOPE    RIZ  OS-258

Manufactured by "Radio industrija Zagreb- RIZ", Zagreb, Croatia, 1958.

SOURCEDubravko Rogale, 9A9DR (Gagi via Jure Šlat)





CATHODE RAY 50 kHz OSCILLOSCOPE  ISKRA MA 4006/Slo

Manufactured by "Iskra", Slovenia,1970.

SOURCE: Dr. sc. Goran Majstorović





DUAL TRACE CATHODE RAY 85 MHz OSCILLOSCOPE   TEKTRONIX  585A

Manufactured in Tektronix, Portland, Oregon, USA

SOURCEZoran Kirchhoffer, dipl. ing.





CATHODE RAY 500 kHz OSCILLOSCOPE     HEATHKIT  IO-12

Manufactured by "HEATH COMPANY", Benton Harbour, Michigan, USA



SOURCE:  Igor Paulinić, Rijeka (via Njuškalo)





CATHODE RAY 500 kHz OSCILLOSCOPE     HEATHKIT  IO-12E

Manufactured by "HEATH COMPANY", Benton Harbour, Michigan, USA

SOURCEDr. sc. Željko Knezić





CATHODE RAY 20 kHz OSCILLOSCOPE    TECH MODEL TO-2

Manufactured by "Tech", Tokio, Japan

SOURCE:  Berislav Mioković, 9A1BM





CATHODE RAY 50 kHz OSCILLOSCOPE   ISKRA MOC-2

Manufactured by "Iskra", Slovenia, early 1950

SOURCE: Sebastijan Tratar, Ljubljana





CATHODE RAY 15 MHz OSCILLOSCOPE    TELEQUIPMENT D43

Manufactured by "Telequipment", London, Great Britain, 1965.

SOURCE:  Mario Božić, Vranjic, via Njuškalo





CATHODE RAY 15 MHz OSCILLOSCOPE   TEKTRONIX  533

Manufactured in Tektronix, Portland, Oregon, USA, 1958.



SOURCE: Dubravko Rogale, 9A9DR (Netretić, Njuškalo)





TRANSISTOR-CURVE TRACER   TEKTRONIX  TYPE 575

Manufactured in Tektronix, Portland, Oregon, USA, 1957.

SOURCE: Dr. sc. Goran Majstorović





TEKTRONIX  TYPE 175 TRANSISTOR-CURVE TRACER  HIGH CURRENT ADAPTOR

Manufactured in Tektronix, Portland, Oregon, USA, 1961.



SOURCE: Dr. sc. Goran Majstorović





CATHODE RAY 400 MHz OSCILLOSCOPE   TEKTRONIX  7834

 Manufactured in Tektronix, Portland, Oregon, USA

SOURCE: Dr. sc.Zlatko Ribić via prof. dr- sc. Siniša Fajt





CATHODE RAY OSCILLOSCOPE / MULTIMETER   GRUNDIG GO 15 D

Manufactured by "Grundig", Germany



SOURCE:  Berislav Mioković, 9A1BM





CATHODE RAY OSCILLOSCOPE   N3013

Manufactured by former USSR

SOURCE:   Dr. sc. Željko Knezić, dipl. ing.





TUBE OSCILLOSCOPE PHILIPS GM 3152B

SOURCE: Krešimir Jesteršabec





TUBE OSCILLOSCOPE PHILIPS GM 3152B

SOURCE: Krešimir Jesteršabec





TUBE OSCILLOSCOPE PHILIPS GM 3152B

SOURCE: Dubravko Rogale (Njuškalo)





TUBE OSCILLOSCOPE SIEMENS KE 1071

Year 1941

SOURCE: Krešimir Jesteršabec





U.S. NAVY TUBE OSCILLOSCOPE   TS-34/AP

SOURCE: Krešimir Jesteršabec





TUBE OSCILLOSCOPE NORDMENDE

SOURCE: Dubravko Rogale





TUBE HOMEBREW OSCILLOSCOPE

SOURCE: Krešimir Jesteršabec





TWO CHANNEL 500 kHz OSCILLOSCOPE  TEKTRONIX  214

Manufactured in Tektronix, Portland, Oregon, USA, 1974.-1991.

SOURCE: Krešo Lerota





CATHODE RAY 24 MHz OSCILLOSCOPE   TEKTRONIX  434

Manufactured in Tektronix, Portland, Oregon, USA, 1971-1984.

SOURCE: Vinko Müller





CATHODE RAY 15 MHz OSCILLOSCOPE   TEKTRONIX  535A

Manufactured in Tektronix, Portland, Oregon, USA, 1954.-1973.



SOURCE: Vinko Müller





CATHODE RAY 30 MHz OSCILLOSCOPE   TEKTRONIX  541

Manufactured in Tektronix, Portland, Oregon, USA, 1955.-1966





CATHODE RAY 30 MHz OSCILLOSCOPE   TEKTRONIX  543B

Manufactured in Tektronix, Portland, Oregon, USA, 1958.-1973.

SOURCE: Duje Blašković





CATHODE RAY 33 MHz OSCILLOSCOPE   TEKTRONIX  545B

Manufactured in Tektronix, Portland, Oregon, USA, 1964.-1973.



SOURCE: Vinko Müller





CATHODE RAY 50 MHz OSCILLOSCOPE   TEKTRONIX  547

Manufactured in Tektronix, Portland, Oregon, USA, 1964-1975

SOURCE: Zvonko Benčić





CATHODE RAY 30 MHz OSCILLOSCOPE   TEKTRONIX  549

Manufactured in Tektronix, Portland, Oregon, USA, 1966.-1973.



SOURCE: Vinko Müller





CATHODE RAY 10 MHz OSCILLOSCOPE   TEKTRONIX  564

Manufactured in Tektronix, Portland, Oregon, USA, 1962.-1973.



SOURCE: Vinko Müller





CATHODE RAY 50 MHz OSCILLOSCOPE   TEKTRONIX  2225

Manufactured in Tektronix, Portland, Oregon, USA, 1987-1992



SOURCE: Zvonko Benčić





CATHODE RAY 2 MHz OSCILLOSCOPE   TEKTRONIX  5110

Manufactured in Tektronix, Portland, Oregon, USA, 1976-1991



SOURCE: Zvonko Benčić





CATHODE RAY 65 MHz OSCILLOSCOPE   TEKTRONIX  7403N

Manufactured in Tektronix, Portland, Oregon, USA, 1970.-1975.



SOURCE: Darko Lukša





CATHODE RAY 100 MHz OSCILLOSCOPE   TEKTRONIX  7633

Manufactured in Tektronix, Portland, Oregon, USA, 19574-1990.



SOURCE: Vinko Müller





CATHODE RAY 500 kHz OSCILLOSCOPE   HP  130C

Manufactured in Hewlett-Packard, USA



SOURCE: Vinko Müller





OSCILLOSCOPE  HAMEG HM 205

SOURCE: Dubravko Rogale





OSCILLOSCOPE  HAMEG HM 204-2

SOURCE: Dubravko Rogale





OSCILLOSCOPE  PHILIPS PM 3215

SOURCE: Toni Oreč





OSCILLOSCOPE  PHILIPS PM 3233

SOURCE: Toni Oreč





OSCILLOSCOPE  PHILIPS PM 3310

SOURCE: Zvonko Benčić





OSCILLOSCOPE   HITACHI  V-222

SOURCE: Zvonko Benčić





PLUG-INS 1A1 AND 1A5 FOR TEKTRONIX OSCILLOSCOPE

SOURCE: Zlatko Šrajber










NA POČETAK STRANICE

MJERNA OPREMA
